JEE Main · 2014 · 06 Apr 2014 · Offline · Rotational Mechanics

WhatsApp Email

A mass 'm' is supported by a massless string wound around a uniform hollow cylinder of mass m and radius R. If the string does not slip on the cylinder, with what acceleration will the mass fall on release?

(A) $\frac{5 g}{6}$
(B)g
(C) $\frac{2 g}{3}$
(D) $\frac{g}{2}$ ✓ Correct

Answer: (D)

Solution

Let the mass fall with acceleration

a

. For the mass,

m g - T = ma

. For the hollow cylinder the moment of inertia is

I = m R^{2}

, and the torque from the string gives

T R = I \frac{a}{R} = m R a

, so

T = ma

. Putting this into the first equation,

m g - ma = ma

, hence

a = \frac{g}{2}

JEE Main · 2014 · 06 Apr 2014 · Offline · Single correct option
