JEE Main · 2022 · 29 Jul 2022 · Shift 1 · Current Electricity

The current I flowing through the given circuit will be ______ A.

Answer: 2

Solution

The circuit simplifies to a series combination. The two 2Ω resistors in parallel give an equivalent resistance of 1Ω. Adding the 2Ω resistor in series gives a total resistance of 3Ω. Using Ohm's law:

I = \frac{V}{R} = \frac{6}{3} = 2 A

JEE Main · 2022 · 29 Jul 2022 · Shift 1 · Integer answer
